Description
Product Specification Table:
| Model | Gear Ratio | Drag (kg) | Weight (g) | Mono Line (mm) | PE Line | Power Pro Braid (lb/yd) | Retrieve Per Crank (cm) | Handle Length (mm) | Bearings |
| 2500HGFK | 5.8 | 9 | 205 | 0.25-160 | 1-320, 1.2-270, 1.5-220 | 10-150, 15-145, 30-100 | 86 | 55 | 8/1 |
| C3000HGFK | 5.8 | 9 | 210 | 0.25-210, 0.30-130, 0.35-100 | 1-400, 1.5-270, 2-200 | 10-200, 20-140, 40-105 | 86 | 55 | 8/1 |
| 4000XGFK | 6.2 | 11 | 265 | 0.30-180, 0.35-130 | 1-490, 1.5-320, 2-240 | 15-230, 30-180, 40-140 | 101 | 57 | 8/1 |
| C5000XGFK | 6.2 | 11 | 270 | 0.35-175, 0.40-120 | 1.5-400, 2-300, 3-200 | 20-260, 30-235, 40-185 | 101 | 57 | 8/1 |
Designed for peak performance in both inshore and freshwater environments, the Shimano Sustain FK combines cutting-edge technologies to deliver enhanced control, strength, and precision. As part of the MAGNUMLITE series, it features an ultra-responsive MGL Rotor that offers exceptional lure control.
Advanced systems like INFINITYDRIVE reduce rotational resistance for smooth, effortless cranking, while INFINITYXROSS reinforces gear engagement for long-term durability. INFINITYLOOP and the ANTI-TWIST FIN work together to improve line lay, minimise slack, and maximise casting distance and consistency.
Finished with a dependable DURACROSS drag system, the Sustain FK is lightweight, robust, and built to perform—cast after cast.
Features & Technology:
- HAGANE Design
Hagane is a Shimano reel design concept created to withstand continual use and extreme abuse. HAGANE is an innovation with built-in toughness and durability that works alongside Shimano's precision engineering. HAGANE is for all anglers.
- MAGNUMLITE Series
MAGNUMLITE SERIES uses a low-inertia rotor (MGL ROTOR) made of carbon fibre reinforced resin CI4+. This results the weight lighter, improving the agility and the sensitivity of the information transmitted to the hand. In addition, by making the rotor's inertia as low as possible, reeling and stopping can be achieved with little force. It is easy to feel the movement of the lure and changes in the water current. It makes it easier to control the lure to catch fish.
- HAGANE Gear
With amazing strength and durability, the HAGANE Gear is at the very heart of most Shimano reels. Shimano, through the application of state-of-the-art technologies, gives anglers the long-lasting smoothness and enjoyment that is felt when anglers first use a reel, over and over again.
- MICROMODULE Gear 2
The MICROMODULE Gear II has evolved with Shimano's unique manufacturing technology and a state-of-the-art gear-tooth surface design. The drive and pinion gear surfaces have been analyzed and updated from the ground up in Shimano's pursuit of perfection to further improve the smooth gear feeling and reduce sound.
- X SHIP
X SHIP provides improved gear performance. Large diameter drive gear, optimally positioned pinion gear and drive gear, and two points bearings supported pinion gear produce light reeling under load.
- HAGANE BODY
The use of lightweight and rigid metals such as aluminum and magnesium firmly suppresses deflection, distortion, and torsion of the reel. This protects delicate gear meshing and enables smooth reeling.
- INFINITYLOOP
Super slow oscillating that goes beyond slow oscillating. The speed at which the spool moves up and down has been made overwhelmingly slow through the evolution of the internal structure. The line is wound around the spool one by one in an orderly and precise manner, and the line release resistance has been successfully reduced significantly. This has realized an exhilarating casting feel and smooth line feed.
- INFINITYXROSS
INFINITYXROSS provides superior gear durability through industry-leading design and cutting-edge manufacturing technology. Advancements in the gear tooth design improve the surface contact and meshing between the drive gear and pinion gear. This revolutionary design efficiently distributes the load placed on the gear tooth surface across a wider area to prevent damage from stress points while significantly improving overall gear durability.
- INFINITYDRIVE
INFINITYDRIVE is a new main shaft supporting structure that improves winding torque and allows for incredibly smooth and light rotation.
- DURACROSS
DURACROSS provides smooth, reliable drag performance and incredible durability. The material is reinforced by weaving in new fibers in a manner orthogonal to the direction of the fibers that make up conventional drag washers. We have succeeded in increasing abrasion resistance more than 10 times while maintaining smooth drag performance.
- SILENT DRIVE
The basic design of the entire body and drive-related parts were reviewed one by one to reduce minute rattles, gaps, and shaking between parts down to the smallest detail. It provides smooth and quiet reel rotation.
- MGL ROTOR
The new design of the MAGNUMLITE ROTOR produces unprecedented light and sensitive rotation. The rotor profile — which was previously symmetrical — is now asymmetrical, and the bail arm mechanism — previously situated on the same side as the line roller — has been moved to the opposite side. Furthermore, the line roller has been lightened, the bail has been made of titanium, and the rotor wall thickness has been optimally arranged to successfully reduce rotational inertia.
- ANTI-TWIST FIN
Elastic fins are installed in close proximity to the line roller section. By suppressing line slack, the fins reduce the phenomenon of line dropping out of the lower part of the spool and line wrapping around the spool while the line is still twisted.
- X-PROTECT
Large reels for saltwater, a contact-type water-resistant structure is used for large spinning reels that require higher water-resistant performance. By physically cutting off the entry path of seawater with a low-sliding seal member, high water-resistant performance is achieved while suppressing rotational resistance. The stopper bearing and line roller parts are adopted, and the stopper bearing part in particular achieves a water-resistant rating equivalent to IPX8.
- G FREE BODY
G FREE BODY technology has been developed to shift the reel's center of gravity closer to the rod. By moving the center of gravity closer to the angler’s hand, the G FREE BODY helps to reduce fatigue and enhance casting comfort.
- AR-C SPOOL
The spool has a special spool ring shape. This creates a rectifying effect on the line and realizes both suppression of line trouble and long casting performance.
- LONG STROKE SPOOL
The LONG STROKE SPOOL has a longer stroke compared to conventional spool designs. It contributes to improved casting feel and distance.
- CI4+
CI4 is a resin material reinforced with carbon fiber that is lighter and has a higher strength than conventional resin material. CI4+ is an advanced version of the original CI4 material.The rigidity and durability have been greatly improved from original CI4 material while maintaining the lightness of the material, making it possible to reduce the size and weight of the reel.
- RIGID SUPPORT DRAG
By strengthening the spool support of the main shaft, the play and fluctuation of the spool during drag operation are reduced. The RIGID SUPPORT DRAG allows smooth and consistent drag delivery.
- S A-RB
S A-RB bearings are put through the same process as Shimano’s A-RB bearings but feature shields on both sides of the bearings. These shields reduce the possibility of salt or sand inhibiting the rotation of the bearing.
- ONE PIECE BAIL
ONE-PIECE BAIL allows the line to travel unimpeded to the line roller. The seamless design reduces friction and decreases the chance of tangles or the line catching on the bail arm.
